Grey 1200mm Machine Laid Grey Blocks 20.1201 Corner End Block 1190x190x190

Build block walls faster than ever before with the 600mm Grey Block from Austral Masonry. Thanks to the Ultralite mix used to create them, each block only weighs 13kg which makes them comparable to standard 20.01 series grey blocks.
Out of stock
SKU
574155816334864700101
POA (inc. GST)
Price does not include delivery
Disclaimer

The product images on this website give a general indication of colour for your preliminary selection. We recommend current product samples are viewed before making your final selection. Product prices displayed on the website do not include delivery fees.

Feature Wall Feature Wall
Internal & External Walls Internal & External Walls
Retaining Walls Retaining Walls
Fences Fences
Loading...

Loading...

Size and Format

Enter wall sizes:

Height

Length

Build block walls faster than ever before with the 600mm Grey Block from Austral Masonry. Thanks to the Ultralite mix used to create them, each block only weighs 13kg which makes them comparable to standard 20.01 series grey blocks.

Details

Overview

Build block walls faster than ever before with the 600mm Grey Block from Austral Masonry. Thanks to the Ultralite mix used to create them, each block only weighs 13kg which makes them comparable to standard 20.01 series grey blocks.

Key Facts

  • Feature Wall, Internal & External Walls, Retaining Walls, Fences

  • 1190

  • 190

  • 190

Technical Data

Length (mm) 1190
Width (mm) 190
Height (mm) 190
Units per Square Metre 4.17
Durability Class General Purpose
Place of Manufacture Oakdale, New South Wales
Units Per Tonne 30.30303030303
Fire Resistance Levels: Structural Adequacy 60 to 240 (see notes)
Fire Resistance Levels: Integrity 240
Fire Resistance Levels: Insulation 240
More Information Maximum slenderness ratio (Srf) calculated from fire tests and AS3700:2018 clause 6.3.2.2 is: 60 minutes: 27.83 non load bearing | 22.93 load bearing, 90 minutes: 27.83 non load bearing | 21.31 load bearing, 120 minutes: 26.32 non load bearing | 20.16 load bearing, 180 minutes: 23.30 non load bearing | 18.54 load bearing, 240 minutes: 21.16 non load bearing | 17.39 load bearing.
Minimum Shell Thickness (mm) 30
Weight 4

BIM Library

Our BIM Library contains JPEG, CAD and Revit files to assist in specifying and building with Austral Masonry .
Please select your required file type to download as many products as needed. Only one format can be downloaded at a time.

1. Select your State

2. Select your BIM Library

3. Select your Range and Variants

Certifications

GECA

We’re proud to have achieved the GECA Claim Authenticated mark for our environmental claim that 10%-20% of the energy used in the manufacturing plant of masonry products at Rockhampton, QLD and Oakdale, NSW sites is solar energy.

More Information

More Information
Colour Detail Grey 1200mm
Length 1190
Product Range Machine Laid Grey Blocks
States Sold In VIC, SQLD, NNSW, SNSW
Swatch https://bwassets.widen.net/content/bwm8fu7vjq/original/Diagram_1200mmGreyCorner.jpg?u=fnyqqq&download=true
